WLT-Y05 2-Fold Single Extension Soft-Close Under-mount Drawer Slide

– For Frameless Cabinet

Specifications

FEATURES – Soft Close Single Extension Under-Mount For Frameless Cabinet – Compatible with 1/2” to 5/8” drawer box material thickness APPLICATIONS – Wood residential and commercial furniture – Drawers requiring concealed slides or soft-close feature SPECIFICATIONS – Load Capacity: 35kgs – Drawer Material Thickness: 1/2” to 5/8” – Length:300mm(12”)-600mm(24”) – Module: Soft-Close – Mounting: Undermount – Travel:Single Extension (2-Fold) – Disconnect: Plug-in Pin – Face-Frame Mounting: No – Type: Roller Bearing – Finish: Galvanized Steel RATING – Load: 35kgs/75lbs. – Compliance ANSI performance standards as established by BIFMA, BHMA and KCMA
